Sunsun Cpf 5000 Bio Pressure Pond Filter UVC 11W

Highlights & details
• Easy maintenance via integrated cleaning function in the top cover
• Ideal combination of filter and UVC technology
• Integrated contamination indicator
• Cleaning equipment for quick and effective cleaning
• Easy and uncomplicated bio-pressure pond filter system

The CPF-pressure pond filter series is among the latest generation of pond filters, combining in a compact system, a high-performance bio-mechanical filter along with the most modern UV technology. The filter is unremarkably dug in at the edge of the pond. The compact way of construction makes the pond technology almost completely disappear. Any and all connections as well as the whole field of technology are found in the top cover. The pond filter can be dug in without any problems. The pond water can be pumped to higher-located waterfalls and from this point return into the garden pond.
The pressure pond filter ensures a stable, biological balance and improves the water quality. Along with the appropriate pump (not included in the supply; please note the maximum volume capacity of the pond pump), this ensures for clear water, thus creating healthy surroundings for the pond inhabitants.

Operation
Pressure pond filters with integrated UV unit are the combination of biological and mechanical filtration and contribute to the effectiveness by a UV-C pond clarifier. Due to their UV radiation, UVC pond clarifiers modify the tertiary and quaternary structure of the algae proteins which causes their destruction. The algae clump, thus forming large parts of particles that can be easily removed from the water circulation by the mechanical pond filtration of the pond filter.
During the bio-mechanical cleaning microorganisms accumulate inside the filter and remove germs and bacteria from the water.
By the way of mechanical filtration, floating particles and dirt remain in the pond filter and do not return into the pond water.

It takes about 4–6 weeks for the filter bacteria to settle sufficiently inside the pond filter. Only then it is reasonable to make use of a UVC-pond clarifier. The so-called starter bacteria help to reduce the time for a new pond filter to start its operation. For this purpose, this kind of bacteria (microorganisms) is grown in laboratories. Bacteria start being active at a temperature of approx. 10–12 °C. The temperature of the pond filter should not exceed 40 °C. It is therefore advisable to place the pond filter in the shadow. It should not be exposed to direct sunlight.
The pressure pond filter disposes of an integrated contamination indicator as well as a mechanical cleaning equipment for filter sponges, thus ensuring a quick and easy cleaning.

Cable cross section (mm²): 3 x 0.75 mm²

Cable length (m): 5 Meter

Cable type: H05RN-F

Colour: black

Dimensions: 380 x 380 x 410 mm

Flow rate (l/h): 8000 Lite

IP code: IP44

Input power: 15 Watt

Leistungsaufnahme: 11 W

Main material: ABS, PP, PC

Mains voltage/frequency (V~/Hz): 220–240 V / 50 Hz

Max. pressure (bar): 0.3 Bar

Max. temperature: 35 °C

Min. temperature: 4 °C

Pond size with fish: 4000 Liter

Pond size without fish: 8000 Liter

Product type: pressurised pond filter

Tank volume (l): 20 Liter

UVC power: 11 Watt

Volumen: 20 l

empfohlene Durchflussmenge: 9.000 l/h
